Made a cool blueprint for the PokéDeck using OnShape! (inspired by Inky)

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/066381d2-e4d7-480c-849f-bbd1e636db64-pokedeck_drawing_v1.png

Currently working on a non-systemd enabled Fedora 42 CoreOS container image with RPi Web Shell built-in! Not gonna bake and export the image because last time it crashed my entire Pi (it's a Pi 5 with 8g of RAM, but apparently the uSD cannot endure it...). However, i will put the completed Dockerfile on the repo! THATS WHY I NEED SSD ASSESORIES!!!

Here's a not-so-good older image (Fedora 41)

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/44903a2d-3366-493a-85ec-a8cef59a4210-image.png

Updated the buttons size and the bottom layer layout again. Also added another button and made ground planes for both layers!

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/4ec9a626-ee71-4eb5-9e88-df049a2196a4-image.png

Changed the layout of all the components on the Bottom layer, brought the pico behind the LCD, and changed the position of the TP4056, JST connector and capacitors. Also replaced the 10uf electrolytic capacitor with a ceramic one and added an ON/OFF switch!

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/a5efd207-7558-4c61-ab0e-8b3a1a3f60d3-image.png

Arranged all the components onto the PCB and made a border. Will start working on the tracing after I finalise the final design of the PCB!

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/84dfa21f-4b57-40a9-892e-118efa5298b3-image.png

Did some work, implmented the ship update method. github.com/hackclub/marketplace/commit/f4f8757fa4712798c93139650b9d329ba912d0d1

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/1401e460-02ed-4ad5-8e0c-600dbcbfcaf4-screenshot_2025-04-17_at_3.23.27___pm.png

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/b24e4d14-cb3d-43e3-af16-71d72c7b7e75-ae3a1092-afd6-4a35-952c-8232e0b94d49.png

this micght workk....

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/7c202531-d6b2-4a6d-a30f-a9e1e4103708-image.png

added a pico and a few leds.... I will add the resistors later

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/1b6ae900-99f1-451e-9d51-7da220683de8-image.png

I scrapped the idea of using OpenCV. I am using the tokio library to asynchronously run libcamera and ffmpeg. I have now got libcam to pipe into ffmpeg, I just need to actually get it to work. I have generated one frame, but I'm pretty sure that its not actually camera data... at least I've got some randomness, and its actually outputting something

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/f72d012d-d768-496d-a5af-7c774ae6dcdf-image.png

Added user avatars to the navbar ;p github.com/hackclub/marketplace/commit/a89daba76f5b2afb0ddb4739e48e064f71dcaa1b

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/cb8172b6-7d9a-4574-a538-a0a54c09bfb0-image.png

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/f941e70e-b87d-4bf0-baeb-031d2b415ae5-f2d7b92d-be08-4b19-a0a8-482ebf30ee38.png

made a case!! should include tolerances for the pcb/screen so they fit in easily, but securely i've managed to get my 3d printer to be precise up to 0.1mm (which i still find crazy) so this should be easy to print just gotta carve out holes for charging and buttons when i design the pcb cad.onshape.com/documents/cb7162e245d0900f508fcb50/w/940c990f9d72fb5903e72538/e/1f520369415ae0e248c4032d check out progress in #C08MTCZ6GCS|!

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/e043d3db-9058-4b81-bbf3-2fae303bd27d-image.png

Coolify is something.. i spent some time working on getting a gh action to make it auto deploy.. github.com/hackclub/marketplace/commits/main/?since=2025-04-15&until=2025-04-15

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/40cb1d32-045c-4b42-b54e-bed0566bb418-image.png

https://scrapbook-into-the-redwoods.s3.us-east-1.amazonaws.com/c8ef08f1-fbf8-41ce-8d0a-b269f5404fe8-e1f9c9ec-abf8-4700-81be-8f1bc1535828.png

was bored so I made a fun little logo & banner for Modulo, based on the planned dot-matrix UI of the app
